4inch Stainless Steel Tube Bending Machine (SB-120NC)

4inch Stainless Steel Tube Bending Machine (SB-120NC)

  • Direct supply from the manufacturer

Phone:+86-15150208940
E-mail:info@hlbender.com

Detail

4inch stainless steel tube bending machine

  • 1. Using Micro computer control,dialogue operation, and easy to set the program
    2. the machine body structure is stable, not easy to deformation
    3. can set 16 bending angle for each pipe
    4. Error message displayed on the screen to help the operator immediately excluded.
    6. can set any bending angle from 0-180degree.
    7. English control panel and program
    8.can bend round pipe, square tube,oval tube, rectangular tube as well as aluminum profile
    9.can bend steel pipe, ss pipe, copper pipe, as well as aluminum pipe
    10. machine voltage can be customized.



Specification/Model SB-114NC
Max bending capacity Φ110×6mm
maxi bending radius 550mm can be customized
Max bending angle 180°
mandrel support length 4250mm can be increased according to customers' option
Control system Micro computer
Number of bending angle for each pipe 16
Store part number 16*16
Oil motor power 22kw
Max pressure 14MPa
Size 5.6*2.0*1.45m
Weight 6000kg
Hydraulic system Magnetic valve
Cooling Water cooling
